Generals Manufacture SINOLIFTLSeries2.0T-3.5TDieselForkliftSpecifications
Model CPC(D)20-X2 CPC(D)25-X2 CPC(D)30-X2 CPC(D)35-X2
CPC(D)20-W1 CPC(D)25-W1 CPC(D)30-X3 CPC(D)35-X3
CPC(D)20-W3 CPC(D)25-W3 CPC(D)30-X4 CPC(D)35-X4
***** ***** CPC(D)30-Y2 CPC(D)35-Y2
***** ***** CPC(D)30-W2 CPC(D)35-W2
Powertype Diesel Diesel Diesel Diesel
Ratedcapacity kg 2000 2500 3000 3500
Loadcenter mm 500 500 500 500
Dimensions Liftheight mm 3000 3000 3000 3000
Freeliftheight (E) mm 140 140 145 145
Forksize (N×U×L) mm 1070*120*40 1070*100*45 1070*125*45 1070*130*45
Masttiltangle (α/β) deg 6/12 6/12 6/12 6/12
Frontoverhang (A2) mm 482 482 501 501
Overalldimensions Lengthtofaceoffork (A1) mm 2510 2580 2720 2720
Overallwidth (B1) mm 1150 1150 1225 1225
Mastloweredheight (H1) mm 1995 1995 2070 2070
Mastextendedheight (H3) mm 4037 4037 4272 4272
Overheadguardheight (H2) mm 2060 2060 2090 2090
Turningradius (R) mm 2170 2240 2460 2460
Min. rightangleaislewidth (X) mm 1920 2010 2110 2190
Performance Travelspeed
(noload/fullload) 		Hydraulic km/h 17/19 17/19 17/19 17/19
Mechanical ShiftI km/h 8.5/9 8.5/9 8.8/9 8.8/9
ShiftII km/h 18.5/19 18.5/19 18.5/20 18.5/20
Liftspeed(fullload) mm/sec 450 450 400 360
Max. gradeability % 20 20 18 15
Selfweight kg 3550 3880 4380 4750
Wheel &Tires Tires Front 7.00-12-12PR 7.00-12-12PR 28*9-15-14PR 28*9-15-14PR
Rear 6.00-9-10PR 6.00-9-10PR 6.50-10-10PR 6.50-10-10PR
Tread FrontB2 mm 970 970 1000 1000
RearB3 mm 970 970 970 970
Wheelbase (A3) MM 1600 1600 1700 1700
Groundclearance
(fullload/noload) 		Mast (M) mm 85/105 85/105 110/135 110/135
Frame (F) 100/105 100/105 130/135 130/135
Driveunits EngineOptions EngineCodeName X2 X3 X4 W1 W2 W3 Y3
Model XINCHA
I490BPG 		XINCHA
I495BPG 		XINCHA
I498BPG 		ISUZU
C240PKJ 		ISUZU
4JG2 		ISUZU
HJ493 		Yanmar
4TNE98
Ratedoutput kw/rpm 37/2650 42/2650 45/2500 34.5/2500 44.9/2450 39/2500 44.3/2300
Ratedtorque N. m/rpm 148/1900 174/1800-2000 191/1600 139/1800 186.3/1600-1800 165/1800 206/1700
No. ofcylinder 4 4 4 4 4 4 4
Bore×stroke mm 90*100 95*105 98*105 86*102 95.4*107 92*93 98x110
Displacement L 2.54 2.98 3.168 2.369 3.059 2.771

Remark:
1. Special lifting height available.
2. Attachment available.
3. The specification in the table are for standard models only. For further information, please contact us.
