General Manufacture SINOLIFT L Series 4.0T-5.0T Diesel Forklift Specifications
Model CPCD40C
-X4		 CPCD40C
-W2		 CPCD40C
-Y2		 CPCD40
-M		 CPCD45
-M		 CPCD50
-M		 CPCD40
-LF		 CPCD45
-LF		 CPCD50
-LF
Power type Diesel (Economic type) Diesel
Rated capacity kg 4000 4000 4500 5000 4000 4500 5000
Load center mm 500 500 500
Dimensions Lift height (H) mm 3000 3000 3000
Free lift height mm 150 150 150
Fork size mm 1070×140×50 1070×150×55 1070×150×55
Fork spread outside Min. /Max. mm 300/1200 300/1200 300/1200
Mast tilt angle deg 6°/12° 6°/12° 6°/12°
Front overhang mm 510 562 562
Overall dimensions Length to face of fork (A1) mm 2935 3091 3091 3125 3091 3091 3125
Length with fork mm 4005 4182 4182 4216 4182 4182 4215
Overall width (B1) mm 1410 1485 1480
Wheel width mm // 1465 1465
Mast lowered height (H1) mm 2235 2380 2380
Mast extended height (H3) mm 4270 4250 4250
Overhead guard height (H2) mm 2180 2290 2290
Turning radius (R) mm 2800 2790 2790 2790 2830
Min, right angle aisle width mm // 3415 3415 3460 3415 3415 3460
Performance No load/full load Travel speed Forward Ⅰ km/h 15/14 15/14 15/14
Forward Ⅱ 19/18 22/20 22/20
Backward Ⅰ 15/14 15/14 15/14
Lift speed mm/sec 450/400 480/450 480/450 480/430 480/450 480/450 480/430
Max. gradeability % 15 20/19 18/17 17/16 20/19 18/17 17/16
Max. drawbar pull KN 18 21 21
Self weight kg 5380 6450 6770 7050 6450 6770 7050
Wheel & Tire Tires Front 250-15-16PR 300-15-18PR 300-15-18PR
Rear 7.00-12-12PR 7.00-12-12PR 7.00-12-12PR
Tread Front (B2) mm 1160 1180 1180
Rear (B3) mm 1100 1190 1190
Wheelbase (Y) mm 1860 2000 2000
Min. ground clearance Mast (M) mm 140/125 175/145 175/145
(no load/full load) Frame (F) 160/155 190/180 190/180
Drive units & control Transmissions Type Hydraulic Hydraulic Hydraulic
Shift FWD/RWD 2/1 2/1 2/1
Operating pressure Mpa 17 17 18 17 17 18 17 17 18
Battery V/AH 2-12V/80AH or 1x12V/120AH 2-12V/80AH 2-12V/80AH
Engine Options Engien Code Name X4 W2 Y2 M LF
Model XINCHAI 498BPG ISUZU 4JG2-E2 YANMAR 4TNE98-E3 MITSUBISHI S6S R4105G25
Rated output kw/rpm 45/2500 44.9/2450 44.3/2300 55.3/2450 59/2300
Rated torque N. m/rpm 191/1600 186.3/1600-1800 206/1700 250/1600 280/1600～1800
No. of cylinder 4 4 4 6 4
Bore×stroke mm 98*105 95.4*107 98*110 94*120 105*120
Displacement cc 3168 3059 3319 4996 4156
Fuel tank capacity L 75 80 80 90 90

Remark:
ISUZU A-6BG1QC-05 and Kubota V3800 engine is also optional.
